Engineering solutions from concept to production
Design. Refine. Deliver.
CAD & Drawing Packs
We create clear, supplier-ready design packs that make quoting and manufacturing straightforward. Including parametric 3D models, fully toleranced drawings, STEP and DXF file exports, simple BOM’s, and crisp manufacturing notes. Baseline DFM checks remove common pitfalls like over-tight tolerances, awkward radii, and non-standard features, so parts are easier to make with predictable lead times. We prioritise clarity: robust datum schemes, realistic fits, and geometry suited to standard tooling to ensure fewer surprises when it comes to production.
DFM Analysis & Optimisation
Already have models or drawings? We review them against real manufacturing constraints and return prioritised, supplier-ready recommendations. Typical improvements include part consolidation, alternate processes or materials, smarter datum strategies, and standard hardware substitutions. You’ll receive a concise report that ranks actions by impact and effort, with updated callouts to support fast re-quoting. Keep implementation in-house or ask us to update the CAD and drawings. The result: designs that are easier, faster, and cheaper to make, without compromising function.
Jig & Fixture Design
We design practical tooling that improves throughput and consistency without over-engineering. Starting from your workflow, targets, and part variation, we propose clear concept options with pros/cons and rough build costs. Once a direction is chosen, we develop a complete design pack: models, assembly drawings, cut lists, and build notes. We favour off-the-shelf components and sensible datum schemes to ensure reliable location, quick loading, and easy maintenance. The outcome is robust, buildable tooling that shortens changeovers and reduces scrap and costs.
